Bachmann Coiled Power Cable H05VV-F 3G1.5mm² 0.3m Black ISV

The Bachmann Coiled Power Cable (Spiralleitung) is a high-quality, flexible power supply cable designed for light and medium duty appliances and equipment. With its coiled design, it offers excellent retractability and space-saving storage, making it ideal for applications where cable management is crucial. This cable is manufactured to the H05VV-F standard, ensuring reliable performance and safety.

Advantages

Coiled construction prevents tangling and reduces clutter. The cable is flame retardant according to IEC 60332-1-2, enhancing safety. PVC insulation and sheath provide durability and flexibility across a wide temperature range.

Suitable for

• Flexible power supply for household appliances, power tools, and office equipment
• Extension cords and portable devices requiring a retractable cable
• Industrial and commercial applications where cable length needs to be adjustable

Key specifications

• Cable Type: Coiled Power Cable (Spiralleitung)
• Cable Standard: H05VV-F
• Conductor Configuration: 3G (3 Conductors with Earth)
• Conductor Cross-Section: 1.5 mm²
• Rated Voltage: 300/500 V
• Retracted Cable Length: 0.3 m
• Cable Color: Black
• Number of Cores: 3
• Earth Conductor: Yes (Green/Yellow)
• Conductor Material: Copper
• Insulation Material: PVC
• Sheath Material: PVC
• Max. Conductor Temperature: +70 °C
• Operating Temperature Range (Flexible): -5 °C to +70 °C
• Operating Temperature Range (Fixed): -30 °C to +70 °C
• Flame Retardant: Yes (IEC 60332-1-2)
• Harmonized Code: H05VV-F

Recommendations

For optimal performance, ensure the cable is used within its specified temperature range and not subjected to mechanical stress beyond its design. This cable is not intended for fixed installations or outdoor use without additional protection.
