Photoelectric sensor Schneider Electric XSAV11373

The Schneider Electric XSAV11373 photoelectric sensor is a compact, robust detector designed for industrial applications. Constructed from nickel brass and rated IP67, it resists dust and water ingress. The sensor operates with a supply/output voltage range of 12–48 V, has a depth of 81 mm and weighs 30 g, offering a space-efficient and durable solution for monitoring and control tasks.

Advantages

The XSAV11373 combines a corrosion-resistant nickel brass body with an IP67 enclosure for reliable operation in harsh environments. Its wide 12–48 V operating range ensures compatibility with common industrial power systems, while the compact 81 mm depth and 30 g weight simplify installation where space and mass are limited. The sensor supports functions such as rotation monitoring, selective detection and analogue control, providing flexibility for varied application needs.

Suitable for

Key specifications

How to use

Mount the sensor according to the machinery manufacturer’s guidelines, ensuring secure fastening and correct alignment with the target. Connect the sensor to a compatible 12–48 V supply and interface it with the control system following wiring diagrams and safety standards. Configure detection thresholds or analogue outputs in the machine controller as required for rotation monitoring, selective detection or analogue feedback. Verify sensor operation through initial tests and periodic checks to confirm reliable detection and signal integrity.

Recommendations

Install the XSAV11373 in locations protected from direct mechanical impact and perform routine inspections for mounting integrity and electrical connections. Use appropriate cable glands and sealing methods to maintain the IP67 rating. When integrating with control systems, document wiring and configuration settings to support maintenance and troubleshooting.
