ALPEN-MAYKESTAG Alpen Pro KP 19 PVC 1-1 10x0.5 Control Cable 10 Core 0.5 mm² Grey

The ALPEN-MAYKESTAG Alpen Pro KP 19 PVC 1-1 10x0.5 is a high-quality control cable designed for industrial and commercial applications. With 10 cores of 0.5 mm² fine-stranded bare copper conductors, this PVC-insulated and sheathed cable offers reliable performance in fixed or flexible installations. It complies with VDE standards and is flame retardant according to IEC 60332-1-2.

Advantages

This control cable provides excellent flexibility due to its Class 5 fine-stranded conductors, making it easy to install in tight spaces. The PVC sheath offers good mechanical protection and limited oil resistance. Color-coded cores simplify identification and termination, reducing installation time.

Suitable for

• Control and signal circuits in machinery and equipment
• Industrial automation systems
• Power supply for small motors and actuators
• Internal wiring of switchboards and distribution panels

Key specifications

• Cable Type: Control Cable
• Number of Cores: 10
• Conductor Cross-section: 0.5 mm²
• Conductor Material: Bare Copper
• Conductor Class: Class 5 (Fine Stranded)
• Insulation Material: PVC
• Sheath Material: PVC
• Core Identification: Color Coded (VDE 0293-308)
• Rated Voltage (U0/U): 300/500 V
• Test Voltage: 2000 V
• Temperature Range (Fixed): -30°C to +70°C
• Temperature Range (Flexible): -5°C to +70°C
• Outer Diameter (Approx.): 9.5 mm
• Minimum Bending Radius (Fixed): 4 x Outer Diameter
• Minimum Bending Radius (Flexible): 15 x Outer Diameter
• Flame Retardancy: IEC 60332-1-2
• Oil Resistance: Limited
• UV Resistance: No
• Sheath Colour: Grey
• Standards: VDE 0245, VDE 0281

Recommendations

For optimal performance, ensure the cable is installed with appropriate bending radii and protected from direct UV exposure. Suitable for indoor use and applications where limited oil contact may occur.
