Allied Telesis AT-GS970M/18PS-50 Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey

Allied Telesis AT-GS970M/18PS-50 Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey
Allied Telesis AT-GS970M/18PS-50 Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey
Allied Telesis AT-GS970M/18PS-50 Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey
Allied Telesis AT-GS970M/18PS-50 Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey
R13,684
Managed Gigabit Edge SwitchesThe CentreCOM® GS970M Series of Layer 3 switches provide high performance with gigabit to the desktop, the ability to connect and power endpoints, and lower management costs—a high value network edge solution from Allied Telesis. Overview- Reduce costs and automate netwo... Read More
Stock Out Of StockNo Stock Code 2374749 Brand ALLIED TELESIS Model 990-005797-50 Warranty 2 Years

Shipping & Returns

Managed Gigabit Edge Switches
The CentreCOM® GS970M Series of Layer 3 switches provide high performance with gigabit to the desktop, the ability to connect and power endpoints, and lower management costs—a high value network edge solution from Allied Telesis.

Overview
- Reduce costs and automate network and device management with the Allied Telesis Autonomous Management Framework™ (AMF)
- Flexible deployment with 10, 18 and 28 port models
- High-speed gigabit network access for power users
- Support converged networks with PoE+ to power devices like wireless access points, digital surveillance cameras and IP phones
- Easy management with an industry-standard Command Line Interface (CLI) and intuitive Graphical User Interface (GUI)

Key Features
- AlliedWare Plus Enterprise-class operating system
- Eco-friendly for reduced running costs
- Network Access Control (NAC) for edge security
- Ethernet Protection Switched Ring (EPSR) enables resilient high-speed ring-based networks
- Static Routing and RIP support Layer 3 environments

Allied Telesis AT-GS970M/18PS-50. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16, Console port: RJ-45. MAC address table: 16000 entries, Switching capacity: 36 Gbit/s. Networking standards: IEEE 802.1AX, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE.... Power connector: DC-in jack. Rack mounting, Form factor: 1U

Key Highlights
  • Managed L3 Web-based management
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 16 Console port: RJ-45
  • 10BASE-T, 100BASE-T, 1000BASE-T
  • MAC address table: 16000 entries Switching capacity: 36 Gbit/s
  • 1U Rack mounting
Specifications
10G support
No
Basic switching RJ-45 Ethernet ports quantity
16
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Buffer size
524 KB
Console port
RJ-45
Copper ethernet cabling technology
10BASE-T, 100BASE-T, 1000BASE-T
Depth
231 mm
Flash memory
64 MB
Form factor
1U
Harmonized System (HS) code
85176990
Heat dissipation
72 BTU/h
Height
44 mm
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Internal memory
256 MB
Jumbo frames
10000
Jumbo frames support
Yes
Latency (1 Gbps)
3.4 µs
Latency (10-100 Mbps)
7.9 µs
LED indicators
Yes
Link aggregation
Yes
MAC address table
16000 entries
Memory type
DDR-SDRAM
Multicast support
Yes
Networking standards
IEEE 802.1AX, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Noise level
34 dB
Non-operating altitude
0 - 4000 m
Number of VLANs
2048
Operating altitude
0 - 3000 m
Operating relative humidity (H-H)
5 - 90%
Operating temperature (T-T)
0 - 50 °C
Package depth
360 mm
Package height
150 mm
Package weight
4.35 kg
Package width
430 mm
Packet buffer memory
1.5 MB
Power connector
DC-in jack
Power consumption (max)
21 W
Power over Ethernet (PoE)
No
Product colour
Grey
Quality of Service (QoS) support
Yes
Rack mounting
Yes
Safety
FCC, EN55022, EN61000-3-2, EN61000-3-3, VCCI, CISPR, EN55024, EN60950-1, UL 60950-1, EN60825-1
SFP module slots quantity
2
Storage relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-20 - 70 °C
Switch layer
L3
Switch type
Managed
Switching capacity
36 Gbit/s
Throughput
26.8 Mpps
Virtual LAN features
Private VLAN, Port-based VLAN
VLAN support
Yes
Web-based management
Yes
Weight
3 kg
Width
341 mm

Leaflet

Open Leaflet

Manual

Open Manual
