AJA 12GDA 12G-SDI 1x8 Distribution Amplifier

AJA 12GDA 12G-SDI 1x8 Distribution Amplifier
AJA 12GDA 12G-SDI 1x8 Distribution Amplifier
AJA 12GDA 12G-SDI 1x8 Distribution Amplifier
AJA 12GDA 12G-SDI 1x8 Distribution Amplifier
R13,677
The AJA 12GDA is a compact mini-converter that takes a single 12G-SDI input and distributes it to eight reclocked outputs, supporting data rates from 270 Mb/s up to 12 Gb/s. Unlike many distribution amplifiers that require separate configurations for different SDI standards, the 12GDA automatically ... Read More
Stock 5 Code 3528059 Brand AJA Model 12GDA Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The AJA 12GDA is a compact mini-converter that takes a single 12G-SDI input and distributes it to eight reclocked outputs, supporting data rates from 270 Mb/s up to 12 Gb/s. Unlike many distribution amplifiers that require separate configurations for different SDI standards, the 12GDA automatically detects and re-clocks the incoming signal, ensuring reliable distribution across mixed 3G/6G/12G workflows without manual intervention.

Highlights

  • 1x 12G-SDI input, 8x 12G-SDI outputs
  • Automatic reclocking and equalization
  • Supports SMPTE 259M, 292M, 344M, 424M, 425M, 2081-1, 2082-1
  • 5-20V DC locking power input
  • Mini-Converter form factor

Full specifications

  • Input: 1x 12G-SDI BNC
  • Output: 8x 12G-SDI BNC
  • Supported data rates: 270 Mb, 1.5 Gb, 3 Gb, 6 Gb, 12 Gb
  • Maximum data rate: 12 Gbps
  • Input return loss: >15dB up to 12GHz
  • Output return loss: >15dB up to 12GHz
  • Power input: 5-20V DC
  • Typical power consumption: 5W
  • Operating temperature: 0 to 40°C (32 to 104°F)
  • Operating humidity: 10-90% non-condensing

Final note

The 12GDA provides a straightforward way to distribute high-bandwidth 12G-SDI signals to multiple destinations with automatic signal conditioning.

Specifications
Brand
AJA
Category
Distribution Amplifier
EAN
892448000991
Model
12GDA
MPN
12GDA
Product type
Distribution Amplifier
Weight
0.1 kg
