AHD HD-CVI HD-TVI CVBS 2MP Varifocal IR Bullet Camera APTI-H83V31

The APTI-H83V31 is a versatile 2MP bullet camera supporting four video standards: AHD, HD-CVI, HD-TVI, and CVBS. Featuring a 1/2.7" CMOS sensor and a varifocal 2.8-12mm lens, it delivers clear 1920x1080p resolution. With 36 IR LEDs providing up to 30 meters of night vision and an IP66-rated metal housing, this camera is ideal for outdoor surveillance.

Advantages

This camera offers flexible installation with its 4-in-1 video output selection, allowing compatibility with various DVRs. The varifocal lens enables precise field-of-view adjustment, while the IR night vision ensures 24/7 monitoring. The IP66 weatherproof rating guarantees reliable performance in harsh conditions.

Suitable for

• Outdoor perimeter surveillance
• Parking lots and entrances
• Warehouses and industrial sites
• Retail stores and offices

Key specifications

• Image Sensor: 1/2.7" CMOS
• Max Resolution: 2MP (1920x1080p)
• Video Standards: AHD, HD-CVI, HD-TVI, CVBS (selectable)
• Lens: Varifocal 2.8-12mm, F1.2
• IR Range: Up to 30m (36 IR LEDs)
• Min. Illumination: 0.01 Lux (AGC ON), 0 Lux with IR
• Noise Reduction: 2D/3D DNR
• WDR: DWDR
• Weatherproof: IP66
• Housing: Metal
• Power: DC 12V, 600mA
• Video Output: 1x BNC
• Operating Temp: -20°C to +50°C

Recommendations

For optimal performance, use a high-quality DC 12V power supply and ensure proper cable connections. The camera is compatible with most AHD/CVI/TVI/CVBS DVRs. Adjust the lens and OSD settings via the joystick for best image quality.
