Aerocool DELTABKV1 ATX PC Case RGB Front Full Side Window 12cm Fan Black

The Aerocool DELTABKV1 Midi Tower Black is a compact PC case designed to combine efficient airflow with an RGB-forward exterior. It includes a full acrylic or tempered glass side panel to display internal components and a distinctive RGB front panel with built-in lighting modes controllable via an LED button. The case supports ATX, Micro ATX and Mini-ITX motherboards and provides multiple fan and radiator mounting options for flexible cooling setups.

Advantages

The case offers enhanced ventilation through front panel air vents and a dual-chamber layout that separates heat-generating components from the main compartment. A dedicated PSU shroud supports additional 120mm fans aimed at graphics card cooling. Front-panel I/O with USB 3.0, USB 2.0, audio and an LED control button provides convenient access to controls and peripherals. Removable bottom dust filter simplifies routine maintenance.

Suitable for

• Compact gaming builds using ATX, Micro ATX or Mini-ITX motherboards
• Systems requiring visible component showcase via a side window
• Configurations that need multiple 120mm fans or a 120mm rear radiator
• Builds with up to 307mm graphics cards (without front fan) and up to 155mm CPU coolers

Key specifications

• Form factor: Midi Tower
• Motherboard support: ATX, Micro ATX, Mini-ITX
• Drive bays: up to 2 x 3.5" and up to 2 x 2.5"
• Fan support: Front 3 x 120mm (max), Top 2 x 120mm (max), Rear 1 x 120mm (max), PSU shroud 2 x 120mm (max)
• Liquid cooling: Rear 120mm radiator (optional)
• Maximum GPU length: up to 307mm (without front fan)
• Maximum CPU cooler height: 155mm
• I/O ports: 1 x USB 3.0, 1 x USB 2.0, HD audio, mic, LED control button, power button
• Material / Color: ABS / Black
• Dimensions (W x D x H): 197 x 357 x 431 mm

How to use

Install the chosen motherboard (ATX, Micro ATX or Mini-ITX) on the standoffs, mount the power supply and route cables via the dual-chamber design to keep airflow paths clear. Fit storage drives in the designated 3.5" and 2.5" bays. Configure cooling by installing fans in the front, top, rear and PSU shroud locations as required; attach a 120mm rear radiator if using liquid cooling. Use the front-panel LED control button to cycle RGB modes and connect peripherals to the USB and audio ports.

Recommendations

For best airflow and component temperatures, leave at least two front intake fan positions free when installing long graphics cards, ensure the PSU shroud fans are oriented to direct air toward the GPU, and clean the bottom dust filter regularly.
