Adapter Rittal 9635.210 for electrical switches, polyamide housing, light grey, 45 mm wide

Adapter Rittal 9635.210 is an installation adapter for electrical switchgear featuring a polyamide housing in light grey. With an overall width of 45 mm, depth of 92.5 mm and height of 160 mm, this adapter is intended to provide mechanical support and insulated connection points for mounting and routing conductors in control cabinets and distribution panels.

Advantages

The polyamide housing offers electrical insulation and resistance to mechanical stress, while the compact 45 mm width helps save space on mounting rails and inside enclosures. The adapter supports organized cable routing and secure mechanical attachment of switches and associated conductors, reducing the risk of accidental contact and improving installation neatness.

Suitable for

When it may not be suitable

This adapter is not a complete switching device; it serves as a mechanical and connection accessory for switch installations. It may not be suitable for applications requiring integrated switching functions, high-voltage insulation beyond typical control-cabinet use, or where different form factors or larger conductor capacities are required.

Key specifications

How to use

Install the adapter on the appropriate mounting rail or panel location aligned with the intended switchgear positions. Route the round conductors into the adapter connection points according to wiring diagrams and tighten any terminal connections per torque recommendations from the switch manufacturer. Ensure that the adapter housing is secured mechanically and that conductor insulation and clearances meet applicable installation standards before energizing the circuit.

What to consider before purchase

Recommendations

Use this adapter as a mounting and connection accessory in low-voltage control and distribution panels. Follow manufacturer instructions for mechanical fastening and wiring torque values, and observe local electrical codes for conductor sizing, insulation, and protective measures.
