Allied Telesis AT-IE048-480-20 Industrial DIN Rail Power Supply 480 W 48 V DC

Allied Telesis AT-IE048-480-20 Industrial DIN Rail Power Supply 480 W 48 V DC
Allied Telesis AT-IE048-480-20 Industrial DIN Rail Power Supply 480 W 48 V DC
R5,559
Allied Telesis AT-IE048-480-20 is an industrial AC/DC power supply for DIN rail mounting. It supplies compatible industrial network equipment with a nominal 48 V DC output and up to 480 W. The input accepts 90–264 V AC. Mount and wire the unit according to the manufacturer installation guide.MPN: AT... Read More
Stock Out Of StockNo Stock Code 2358389 Brand ALLIED TELESIS Model 990-006325-20 Warranty 2 Years

Shipping & Returns

Allied Telesis AT-IE048-480-20 is an industrial AC/DC power supply for DIN rail mounting. It supplies compatible industrial network equipment with a nominal 48 V DC output and up to 480 W. The input accepts 90–264 V AC. Mount and wire the unit according to the manufacturer installation guide.

MPN: AT-IE048-480-20

Key Highlights
  • ۼ Electromagnetic immunity for industrial environments
  • ۼ High efficiency
  • ۼ Active PFC
  • ۼ Stable output power with 150% peak current capability
  • ۼ Wide input voltage range
  • ۼ Protections: peak-current, over-current and over-temperature
  • ۼ Remote ON/OFF
  • ۼ Output power confirmation relay (DC_OK)
  • ۼ Extended operating temperature range
  • ۼ Air convention cooling
  • ۼ Metal case
  • ۼ DIN rail mount
Specifications
Brand
Allied Telesis
Category
Network Equipment Power Supplies
Compliance certificates
RoHS, WEEE
Cooling type
Passive air convection
Depth
117 mm
Efficiency
94% @ 230 V AC
Export Control Classification Number (ECCN)
5A992C
Form factor
DIN rail
Harmonized System (HS) code
8504.40.8500
Height
124 mm
Housing material
Metal
Input frequency
50/60 Hz
Input operation voltage (max)
264 V AC / 350 V DC
Input operation voltage (min)
90 V
LED indicators
Alarm, Status
Maximum current
15 A
Nominal input voltage
90–264 V AC / 98–350 V DC
Nominal output voltage
48 V
Operating relative humidity (H-H)
20 - 90%
Operating temperature (T-T)
-25 – 70 °C
Output operation voltage (max)
55.2 V DC
Output power
480 W
Power factor
0.98 @ 115 V AC
Power protection features
Over current, Over voltage, Overheating
Product colour
White
Product type
Industrial DIN rail power supply
Storage relative humidity (H-H)
20 - 90%
Storage temperature (T-T)
-40 - 85 °C
Weight
1.2 kg
Width
70 mm

Leaflet

Open Leaflet
