ABUS Terxon SX Wired Alarm System Control Panel with 8 Zones and Integrated PSTN Dialer

For a small shop owner who needs dependable intrusion detection without complex networking, the ABUS Terxon SX wired alarm panel delivers straightforward protection. This control unit manages up to 8 hardwired zones, each supporting normally closed, normally open, or end-of-line resistor configurations, making it compatible with a wide range of door contacts, motion detectors, and glass break sensors. The metal housing includes a dedicated tamper zone to alert you if someone tries to open the panel. Three programmable outputs let you trigger external devices like strobes or additional sounders, while the integrated PSTN dialer can call up to four phone numbers to report alarms. With support for up to 8 user codes and 4 wired keypads, it suits homes and small businesses that need multiple access levels. The panel runs on 230V AC mains and accepts a 12V backup battery (not included) for continued operation during power outages. Its 250-event memory helps you review recent activity, and the optional IP module allows future expansion to network monitoring. Certified to VdS Home standards, this panel is a solid foundation for a basic wired security system.

Key specifications

• 8 wired zones, expandable to 32 with additional modules
• 1 tamper zone for housing protection
• 3 programmable outputs (PGM) for external devices
• Integrated PSTN dialer for alarm calls
• Supports up to 8 user codes and 4 wired keypads
• Metal housing, operating temperature -10°C to +40°C
• 230V AC mains, 12V DC auxiliary output (max 700mA)
• 250-event memory, VdS Home certified

Why choose it

The Terxon SX stands out for its simplicity and reliability. Wired zones are immune to wireless interference, ensuring stable signal transmission. The tamper zone adds an extra layer of security, and the integrated dialer means you don't need an external communicator for basic alarm reporting. Its modular design allows future expansion, protecting your investment.

Ideal use cases

• Small retail stores needing basic perimeter protection
• Residential homes with pre-wired sensor loops
• Offices requiring multiple user access levels
• Installations where wireless signals are unreliable

Good to know

Installation requires basic electrical knowledge and adherence to local regulations. The backup battery is not included; a 12V 7Ah sealed lead-acid battery is recommended. The panel can be wall-mounted using the provided keyholes. For remote monitoring, an optional IP module can be added. The panel is not suitable for outdoor use; install it in a dry, protected location.
