ABB S200 1P C16 Miniature Circuit Breaker 6kA 16A 230/400V AC 2CDE281001R0016

Electricians and panel builders rely on the ABB S200 series for dependable overcurrent protection in residential and commercial distribution boards. This 1-pole miniature circuit breaker (MCB) with C characteristic and 16 A rated current is engineered to safeguard cables and equipment against overloads and short circuits, ensuring safe operation of lighting and socket circuits. Its compact design and DIN rail mounting make installation straightforward in any standard consumer unit.

Key specifications

• Series: S200
• Number of poles: 1P
• Rated current (In): 16 A
• Tripping characteristic: C
• Rated voltage (Ue): 230/400 V AC
• Rated short-circuit breaking capacity (Icn): 6 kA
• Frequency: 50/60 Hz
• Mounting type: DIN rail
• Terminal type: Screw terminals
• Degree of protection: IP20
• Standard: IEC/EN 60898-1
• Electrical endurance: 10,000 cycles
• Mechanical endurance: 20,000 cycles
• Connection capacity rigid: 35 mm²
• Connection capacity flexible: 25 mm²
• Color: Multicolor
• Material: Metal, Plastic

Why choose it

The ABB S200 MCB offers robust protection with a high breaking capacity of 6 kA, ensuring safety even under fault conditions. The C tripping characteristic is ideal for circuits with moderate inrush currents, such as lighting and socket outlets. Its screw terminals accommodate large conductor cross-sections, providing secure and reliable connections. With a mechanical endurance of 20,000 operations, this breaker delivers long-term reliability.

Ideal use cases

• Protection of lighting circuits in residential buildings
• Socket outlet circuits in commercial installations
• Distribution boards requiring DIN rail mounting
• Applications where a 16 A rated current and C curve are specified

Good to know

The breaker is compliant with IEC/EN 60898-1, ensuring it meets international safety standards. It is designed for use in ambient temperatures up to 40°C without derating. The multicolor housing with metal and plastic components provides durability and clear identification. The product includes the breaker only; additional accessories such as auxiliary contacts or shunt trips are available separately.
