2N RFID Reader USB 125 kHz Black

The 2N RFID Reader is a compact and reliable USB device designed for secure access control and identification applications. Operating at 125 kHz, it supports EM4100 and HID Prox standards, making it compatible with a wide range of RFID tags and cards. The reader is bus-powered via USB 2.0, eliminating the need for an external power supply, and features a multi-color LED for status indication. With a read range of up to 5 cm and a 1.5-meter USB-A cable, it offers flexible placement on any desktop. Its robust ABS plastic housing ensures durability in various environments, and it is certified CE, FCC, and RoHS.

Advantages

Plug-and-play installation with driverless support for Windows, Linux, and macOS. Compact desktop design saves space. Low power consumption (max 100 mA) and wide operating temperature range (-20°C to 55°C) ensure reliable performance in demanding conditions.

Suitable for

• Access control systems in offices, warehouses, and secure facilities
• Time and attendance tracking
• Identification and authentication in kiosks or self-service terminals
• Integration with existing 2N intercom and access control solutions

Key specifications

• Product Type: RFID Reader
• RFID Frequency: 125 kHz
• Interface: USB 2.0
• Supported Standards: EM4100, HID Prox
• Power Source: USB Bus Powered (5V DC)
• Current Consumption: Max 100 mA
• Read Range: Up to 5 cm
• Cable Length: 1.5 m (USB-A)
• Indicators: Multi-color LED
• Housing Material: ABS Plastic
• Color: Black
• Operating Temperature: -20°C to 55°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 10% to 90% (non-condensing)
• Certifications: CE, FCC, RoHS

Recommendations

For optimal performance, use with 125 kHz passive RFID tags. Ensure the USB port provides sufficient power (5V, 500 mA). The reader is driverless on most operating systems, but check compatibility with your specific OS version.
