2-way Speaker Omnitronic C-40 Black Wired 35 W

The Omnitronic C-40 Black Wired 35 W is a dedicated 2-way PA speaker designed for fixed installations. It combines a 4" (10 cm) woofer and a 1" (2.5 cm) dome tweeter in a trapezoidal ABS cabinet with a metal grille and a movable mounting bracket, allowing wall, ceiling or corner placement. The speaker is wired, delivers 35 W nominal power, and offers a frequency response of 50–20,000 Hz with 8 Ω impedance and 89 dB sensitivity, suitable for public-address and background-music applications in commercial and leisure environments.

Advantages

The Omnitronic C-40 provides clear two-way sound reproduction from a compact housing suitable for discreet installation. Its trapezoidal shape and adjustable mounting bracket enable flexible placement in corners, on walls or ceilings. The ABS housing with metal grille ensures durable protection, while the wired connection and standard impedance make integration with existing PA amplifiers straightforward.

Suitable for

Key specifications

How to use

Mount the Omnitronic C-40 using the supplied movable bracket on a wall or ceiling, or install it in a corner where the trapezoidal cabinet fits. Connect the speaker to a compatible amplifier or PA system using standard speaker wiring, observing polarity and the 8 Ω nominal impedance. Adjust amplifier levels to match the speaker's 35 W rating and sensitivity to avoid distortion and ensure even coverage in the listening area.

Recommendations

For best results in permanent installations, position speakers to provide even coverage and avoid placing them too close to reflective surfaces. Use an amplifier with appropriate power and headroom, and check connections regularly. For background music and PA use, moderate volume settings help preserve clarity and extend speaker life.
