Legrand Keor ASI MULTIPLUG 800 FR uninterruptible power supply (UPS) Line-Interactive 0.8 kVA 480 W 6 AC outlet(s)

The Legrand Keor ASI MULTIPLUG 800 FR is a line-interactive uninterruptible power supply (UPS) delivering 0.8 kVA (480 W) of rated output power. It is CPU-controlled and uses an internal valve-regulated, hermetically sealed lead-acid battery (7 Ah, 12 V). The unit includes an automatic voltage regulator (AVR) to protect connected equipment from mains fluctuations and offers six Type E AC outlets plus one USB 2.0 port in a compact, two-colour (white and black) enclosure. It is certified to EN 62040-1 and EN 62040-2 standards.

Advantages

The UPS provides uninterrupted power and mains conditioning through its line-interactive topology and built-in AVR. Internal sealed lead-acid battery technology ensures safe, maintenance-free operation, while CPU control manages battery charging and transfer to battery power. Certification to EN 62040 standards confirms compliance with relevant safety and electromagnetic compatibility requirements. The unit’s multiple AC outlets and a USB port enable connection of several devices without additional adapters.

Suitable for

• Home or small office computers and workstations
• Networking equipment (routers, modems, small switches)
• Point-of-sale terminals and retail systems
• Monitoring devices and small servers with low power draw

Key specifications

• Output power: 480 W
• Output power capacity: 0.8 kVA
• AC outlets: 6 Type E outlets
• USB: 1 × USB 2.0 port
• Battery: sealed lead-acid 7 Ah, 12 V
• Weight: 5.5 kg
• Colours: White and Black
• Standards: EN 62040-1, EN 62040-2

How to use

Place the UPS on a stable, flat surface with adequate ventilation and connect it to a grounded mains outlet. Plug equipment into the Type E AC outlets and, if needed, connect devices to the USB port. Turn the unit on using the front-panel controls; the CPU-controlled system will manage charging and switch to battery power automatically if mains voltage deviates beyond safe limits. Periodically verify battery status and perform replacements according to the manufacturer’s battery service life recommendations.

Recommendations

Install the UPS in a dry, dust-free environment away from heat sources. Do not obstruct ventilation openings. For optimal runtime, avoid connecting loads that exceed the 480 W rating and replace the sealed lead-acid battery with the manufacturer-recommended type when capacity degrades.
